Replacer

ICache replacer uses PLRU update algorithm.

Similar to MetaArray interleave, considering each fetch may access two consecutive cachelines, one replacer is used for odd addresses and another for even addresses. During touch and victim selection, corresponding replacer is selected by address parity.

PLRU Algorithm

PLRU uses a tree structure to best-effort track the least recently used line. With ICache default 4-way configuration as example, PLRU uses 3 bits to track usage of 4 ways, as shown in 此图. When one state bit is 0, it means lines in left subtree are less recently used; when it is 1, it means lines in right subtree are less recently used. On each access, state bits are updated according to accessed way position in the tree. For example, if way0 is accessed, update state[0]=1 (meaning between way0 and way1, way1 is less recently used) and state[1]=1 (meaning between way0/1 and way2/3, way2/3 are less recently used). When selecting victim, traverse from root following state bits until leaf, then victim way is obtained.

PLRU algorithm illustration

Please also refer to rocket-chip implementation.

touch

Replacer has two touch ports corresponding to two cachelines of one fetch request. Touch update is sent to corresponding replacer according to touch address parity.

victim

Replacer has only one victim port because at any time only one MSHR request is sent to bus. Victim waymask is similarly selected from corresponding replacer by address parity. Internal touch update is then performed for that replacer in next cycle.
